Intellitronix LED Digital Gauge Cluster Set With Black Faceplate For 68 Chevrolet Caprice / Impala
The modernized dash kit comes complete with direct fit printed circuit board, custom fit smoked plexiglass faceplate, universal temperature & oil pressure sending units.
Features
- Speedometer: Reads up to 255 MPH and features odometer, trip meter, one-button calibration, regardless of tire size, gear ratio, or transmission, and 0-60 time, 1⁄4 mile elapse time, and high speed recall, all with the push of a button.
Tachometer: Displays 0-9999 RPM In 9999, 9990, 9900 RPM Increments and is programmable for 4-6-8-cylinder engines.
Water Temperature: Displays 100-300°F range and sending unit is included. If you need a 3/8″ bushing, please note on your order, because we send the more common 1/2″” bushing–otherwise, you will have to supply the bushing on your own.
Oil Pressure: Reads 0-100 PSI and sending unit S8868 is included.
Voltmeter: Reads 7.0-18.0 volts range
Fuel Level: Reads 0-99% range in 1% increments and is programmable for 73-10-20, 220-20, 0-90, 10-180 ohms.
The panel includes turn signals, high beam, brake, and 4-wheel drive indicator.
Easy Install, Lifetime Warranty, Great Price, & Gauges for your very special classic vehicle.
If using factory equipment, GPS (S9020) will be required for speed signal
NOTE: BEZEL NOT INCLUDED
NOTE:DOES NOT WORK WITH A CAN BUS SYSTEM DIRECTLY
Fitment:
- 1968 Chevrolet Caprice
- 1968 Chevrolet Impala
Note: Image is for reference only, actual product may vary slightly.
